The Apex is Pinnacle’s largest listed generator platform, designed for demanding applications where ozone capacity and process integration are central to system selection.
Product Gallery
Benefits

Maximizes Efficiency
High ozone production with minimal energy use.

Reduces Operational Costs
Energy-efficient design lowers overall expenses.

Easy to Install and Maintain
Simplifies both installation and ongoing maintenance.
Applications
Technical specifications
Enclosure |
Sealed NEMA 12 with Integral Cooler Optional: NEMA 4X with Integral Cooler | |
| Minimum Clearance | Front/Back/Right 36 in (915 mm) / Left 18 in (457.5 mm) | |
| Dimensions (LxDxH) | 111” (2,820 mm) x 35” (889 mm) x 103” (2,616 mm) | |
| Weight | ~5,100 lb. (2,313 kg) | |
Facility Connection Requirements |
Oxygen Inlet | 1-1/2″ 316 SS, Class 150 Flange |
| Ozone Outlet | 1-1/2″ 316 SS, Class 150 Flange | |
| Cooling Water Supply (CWS) & Return (CWR) | 2″ 316L SS, Class 150 Flange | |
| Electrical Service | 230 VAC/3PH/60Hz/400A (327 FLA) | |
| Compressed Air Feed | 1/4″ Push Lock Fitting | |
Ozone Output |
Ozone Output (LOX) | up to 328.3 kg/d (723.8 ppd) @ 10% - 371.5 kg/d (819.0 ppd) @ 8% conc. |
| Ozone Output (PSA) | up to 276.5 kg/d (609.6 ppd) @ 10% - 302.4 kg/d (666.7 ppd) @ 8% conc. | |
| Outlet Pressure | 20 psig Optional: up to 25 psig | |
Oxygen Requirements |
PSA, VSA, VPSA or LOX O2 Acceptable | |
| Maximum Oxygen Flow Rate | 2,790 slpm @ 20 psi inlet pressure | |
| Gasified Liquid Oxygen Feed | Dew Point: <-65C, Total Hydrocarbons (as CH4) <15 ppm. | |
| PSA oxygen feed | oxygen concentration ≥ 93% | |
| Max 0.1 µm Filter Inlet (not included) | ||
| N2 Feed NOT required. | ||
Cooling Water Requirements |
Type | Closed-Loop Chilled Water |
| Fluid | Food Grade Glycol-Water Blend (30/70 blend, not included) | |
| Typical Required Cooling Water Flow | ~68 gpm | |
| Cooling Load | ~33.0 Ton | |
Controls & Communication |
Schneider Electric Modicon M251 PLC Controller | |
| 15” RedLion™ Color Touch Screen HMI | ||
| Remote Access | Ethernet/IP/Webserver Interface. Ethernet Switch Provided. Optional: Cellular Modem (Cell Service Not Included) | |
| Uninterruptible Power Supply | ||
Controls Routines |
All Routines Available at Fixed or Variable O3 % BW | |
| Automatic | PID ORP (mv) or PID DO3 (ppm) | |
| Manual | Fixed Output (ppd or kg/h) or Full Manual | |
Accessories & Instrumentation |
|
|
Compliance & Certifications |
|
|
case studies
Learn about the tangible results our clients have experienced with our ozone generator, showcasing its effectiveness and versatility.
